Quick Details

  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: MUST
  • Model Number: PV1800series800W-4kw
  • Output Power: 1 - 200KW
  • Output Type: Single
  • Size: 388*415*200mm
  • Weight: 26kg-32kg
  • Input Voltage: 230VAC
  • Output Voltage: 230V
  • Type: DC/AC Inverters
  • Output Frequency: 50HZ/80HZ
  • Output Current: 12V/24V/48V
  • color: Red
  • display: LCD
  • Voltage: 12v/24v/48vdc
  • frequency: high frequency
  • battery charger current: max 60amp
  • backup time: No limited
  • inverter: home applications
  • efficiency: 98%
  • transfer time: 10MS
  • Storage temperature: 15°C below zero to 60°C

Packaging & Delivery

Packaging Details 1pcs per carton, carton size: 668*425*271mm. one piece gross weight:17kgs. 450pcs for 20ft container
Delivery Time 15-20workdays for order under 2,000pcs, Sample order 5 days

CE certificated Expert on off grid Hybrid 2kva 3kva 4kva 5kva solar inverter

 Spec



RATED POWER1000VA / 800W2000VA/
1600W
3000VA / 2400W4000VA / 3200W5000VA / 4000W
INPUT
Voltage230 VAC
Selectable Voltage Range170-280 VAC (For Personal Computers) ; 90-280 VAC (For Home Appliances)
Frequency Range50 Hz/60 Hz (Auto sensing)
OUTPUT
AC Voltage Regulation
(Batt. Mode)
230 VAC ± 5%
Surge Power2000VA4000VA6000VA8000VA10000VA
Efficiency (Peak)90%93%
Transfer Time10 ms (For Personal Computers) ; 20 ms (For Home Appliances)
WaveformPure sine wave
BATTERY
Battery Voltage12 VDC24 VDC48 VDC
Floating Charge Voltage13.5 VDC27 VDC54 VDC
Overcharge Protection15 VDC30 VDC60 VDC
Maximum Charge Current10 A or 20 A20 A or 30 A60 A
SOLAR CHARGER (OPTION)
Charging Current50 A
Maximum PV Array Open Circuit Voltage30 VDC60 VDC105 VDC
Standby power Consumption1 W2 W2 W
PHYSICAL
Dimension, D x W x H (mm)95 x 240 x 316100 x 272 x 355125 x 297.5 x 468
Net Weight (kgs)5.06.46.99.89.8
OPERATING ENVIRONMENT
Humidity5% to 95% Relative Humidity(Non-condensing)
Operating Temperature0°C - 55°C
Storage Temperature-15°C - 60°C





Packaging & Shipping





Company Information

Shenzhen Must Power Limited established in 1998, which is a professional hi-tech enterprise specialized in Power Inverter,Solar Power, and Battery development, manufacturing, sales and after-service.

Our comprehensive product lines include: Power inverter, Solar inverter, Solar charge controller, Solar battery, Solar power Pack and some other related Solar products.Most of products from Mustups applied with ISO, CE, FCC certificates. The main markets are Ukraine, Russia, Vietnam, Thailand, Pakistan, India, etc.

 Our Services

Payment & Shipping & Sample

1. Payment: T/T (Telegraphic transfer), and Western Union

2. Shipping: DHL, FEDEX, UPS, EMS, Airway and By Sea

3. Delivery time: 7 workdays for sample order



Warranty :

Our product warranty is valid for 12 months after delivery. We undertake to repair  any  malfunctioned units due to defective components of inadequate workmanship ,but specially expecting any defects resulting from normal wear and tear of improper use of the products.

Guides and After-service Consultancy

Must Power Team will offer these guides below.

  A. Need a Accessory

  B. Products Repair

  C. Power Problems to Solve

 D. Power Protection Solutions, etc.



Samples and OEM

Samples are Available for Testing and Market Test. OEM is welcomed for us.
