Quick Details

  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: OEM
  • Model Number: PV3000
  • Output Power: 1 - 200KW
  • Output Type: Single
  • Size: 580*365*310mm
  • Weight: 30kg
  • Input Voltage: 110V/220V/230V/240V
  • Output Voltage: 110V/220V/230V/240V
  • Type: DC/AC Inverters
  • Output Frequency: 50 60hz
  • Output Current: 30A-75A
  • Status display: LCD
  • Photovoltaic(PV) modules: YES
  • Inverter type: Off grid inverter
  • Color: Black or White
  • Frequency: Low frequency
  • DC voltage: 12v/24v/48v
  • Terminal size: #8 AWG
  • MPPT inbuilt: YES
  • Iron case: YES
  • Name: mppt solar inverter/charger

Packaging & Delivery

Packaging Details Cartons or wooden box, Or according to customer's need. Packing siez: 570*315*300mm(1-3KW); 755*319*288mm(4-6kw). 400pcs/20'ft, 900pcs/40'ft
Contact:Nancy
Whatsapp:+86 135 9781 0791
Skype: mustupsc



MUST HOT SALE!!! 1000w 2000w 3000w 4000w 5000W 6000w pure sine wave mppt solar inverter/charger

Product Description

***************ANY QUESTIONS, PLS FEEL FREE TO ASK NANCY!!!!*****************



      WHATSAPP: 008613597810791         SKYPE: mustupsc         Wechat:nancyma0907

  solar inverter charger



1.What Are Features of Solar Power Inverter ?

1. Low Frequency Solar Inverter,Dc to Ac Power4. 12v 60A MPPT Solar Charger Controller7. By Pass Input: AC Grid or Generator
2. DC Batt Volt: 12V/24V/48v5. Running Motor 1HP 2HP 3HP8. LCD Display, with Battery Cable
3. 120V/ 230V 50Hz/60Hz, Pure Sine Wave Output6. Pure Cooper Transformer Built-in9. with RS232 for monitoring





2. What's the Special function: Battery Priority?
When you choose battery priority(Battery type selector on 7-9), then inverter will invert from battery despite the AC input. Only when the battery voltage reaches low voltage alarm point will be inverter transfer to AC input, charge battery and switch back to battery when the battery is fully charged. This function is mainly for wind/'solar systems using utility power as back up.



3.What's the specifications?



MODELPV30-1KWPV30-1.5KWPV30-2KWPV30-3KWPV30-4KWPV30-5KWPV30-6KW
Default Battery System Voltage12VDC24VDC12VDC24VDC12VDC24VDC12VDC24VDC24VDC/48VDC24VDC/48VDC24VDC/48VDC
INVERTER OUTPUTRated Power1KW1.5KW2KW3KW4KW5KW6KW
Surge Rating (20ms)3KVA4.5KVA6KVA9KVA12KW15KW18KW
Capable Of Starting Electric Motor1HP1HP1HP2HP2HP3HP3HP
WaveformPure sine wave/ same as input (bypass mode)Pure sine wave/ same as input (bypass mode)
Nominal Output Voltage RMS100V/110V/120VAC  220V/230V/240VAC(+/-10% RMS)100V/110V/120VAC
220V/230V/240VAC
220V/230V/240VAC
Output Frequency50Hz/60Hz +/-0.3 Hz50Hz/60Hz +/-0.3 Hz
Inverter Efficiency(Peak)>88%>88%
Line Mode Efficiency>95%>95%
Power Factor0.81.0
Typical Transfer Time10ms(max)10ms(max)
AC INPUTVoltage230VAC230VAC
Selectable Voltage Range96~132VAC  155~280VAC(For Personal Computers)96~132VAC/155~280VAC(For Personal Computers)
Frequency Range50Hz/60Hz (Auto sensing) 40-80Hz50HZ/60HZ (Auto sensing)  40-80Hz
BATTERYMinimum Start Voltage10.0VDC /10.5VDC for12VDC mode (*2 for 24VDC, )20.0VDC~21.0VDC /40.0VDC~42.0VDC
Low Battery Alarm10.5VDC +/-0.3V for12VDC mode (*2 for 24VDC, )21.0VDC+/-0.6V /42.0VDC+/-1.2V
Low Battery Cutoff10.0VDC +/-0.3V for12VDC mode (*2 for 24VDC, )20.0VDC+/-0.6V /40.0VDC+/-1.2V
High Voltage Alarm16.0VDC +/-0.3V for12VDC mode (*2 for 24VDC, )32.0VDC+/-0.6V  /64.0VDC+/-1.2V
High Battery Voltage Recover15.5VDC +/-0.3V for12VDC mode (*2 for 24VDC, )31.0VDC+/-0.6V  / 62.0VDC+/-1.2V
Idle Consumption-Search Mode<25W when power saver on<50W when power saver on
AC CHARGEROutput VoltageDepends on battery typeDepends on battery tvpe
Charger AC Input Breaker Rating10A30A30A30A40A
Overcharge Protection S.D.15.7VDC for 12VDC mode (*2 for 24VDC, )31.4VDC/62.8VDC
Maximum Charge Current35A20A45A25A65A35A75A45A65A35A70A40A75A50A
BYPASS
& PROTECTION
Input Voltage WaveformSine wave (grid or generator)Sine wave (grid or generator)
Nominal Input Frequency50Hz or 60Hz50Hz or 60Hz
Overload Protection (SMPS Load)Circuit breakerCircuit breaker
Output Short Circuit ProtectionCircuit breakerCircuit breaker
Bypass Breaker Rating10A15A30A30A40A
Max Bypass Current30Amp40Amp
SOLAR CHARGERMaximum PV Array Power600W1200W600W1200W600W1200W600W1200W1600W3200W1600W3200W1600W3200W
Maximum PV Charge Current40A60A
DC Voltage12V/24V atuo work24V/48V atuo work
MPPT Range @ Operating Voltage16~100VDC32~145VDC @ 24V / 64~145VDC @ 48V
Maximum PV Array Open Circuit Voltage100VDC145VDC
Maximum Efficiency>90%>98%
Standby Power Consumption<2W<2W
MECHANICAL SPECIFICATIONSMountingWall mountWall mount
Dimensions (W*H*D)460*277*192mm597x277x198mm
Net Weight (Solar CHG) kg18.32223.523282739.648.648.6
Shipping Dimensions(W*H*D)554*360*300mm743*372*312mm
Shipping Weight (Solar CHG) kg21.924.826.525.6313043.35353
OTHEROperation Temperature Range0°C to 40°C
Storage Temperature-15°C to 60°C
Audible Noise60dB MAX
DisplayLED+LCD
Loading(20GP/40GP/40HQ)460pcs  /  920pcs   /  1060pcs320pcs  /  640pcs   /  750pcs





4.LCD Display Information and Solar System Connection





5.. Outside picture





6.Customers Installation Picture





Packaging & Shipping



1.Package: Carton Box for packaging, or Wooden Box advised  for Samples to protect in transportations. Package designed

by Clients is welcomed.

2.Shipping: DHL,FEDEX,UPS,EMS,AirWay and By Sea.

3.Payment: T/T( telegraphic transfer (T/T) and Western Union

4.Welcome to your Sample Order to test First.



 Client's OEM Package Welcomed



Shipping of Pure sine wave power inverter: By SEA, By Air-way, By Courier





OUR PACKING :









Our Services

 Samples and OEM, Warranty and After-Sale Service:

  •  Welcome Solar Power Inverter Sample Test
  •  OEM Welcomed
  •  Warranty:1 Year
  •  After-Sale Service: 24 Hour-Hot Line for Consultacncy and Technical Support
How To Ask for Support if products failure in warrenty?
1. email us about PI number, serial number,Product S/N number, PCB board number most importantly, is the description of failure products on the condition that it is operated correctly, to the best, show us more detailed pictures or video.
2. we will submit your case to our after sales department.
3.Usually within 24 hours, we will email you the best solutions.

Overseas After-Sales Office Information :
Pakistan office:

IMRAN & CO
Add: 23 Mughal Centre, Link Hall Road, Lahore,Pakistan
PH # 0423 7239208





Company Information



Do you know MUST POWER LIMITED?

  •   Established in 1998, Headquarter in HongKong
  •  10-year Professional Factory Manufacturer in Shenzhen, China
  •   Product Range: Power Inverter, Solar Inverter, MPPT Solar Charge Controller, Solar Battery,     UPS
  •   Main Market : Ukraine, Russia, Vietnam, Pakistan, Nigeria, Kenya,etc.
  •  Three-Floor Factory Building, 10000 Square Meters, Two Manufacturing Centers, QA Office, Aging Test Area and Two Teams of R & D.
  •  Certificate: ISO 9001, SGS Certificate, CE, etc
  •  6-Year Alibaba Gloden Supplie



MUST FAMILY

Must Showroom


Must Exihibitions

Must Certificate


FAQ



Q1: How to choose a right inverter?

A1:Tell us your demand, then our sales will recommend a suitable inverter to you.

 Q2: What's the different between inverter and solar inverter?

A2:  Inverter is only accept AC input, but solar inverter not only accept AC input but also can connect with solar panel to accept PV input, it more save power.

 Q3: How about the delivery time?

A3:  7 days for sample; 25 days for bulk order.

 Q4: What is the warranty of inverter?

A4: One year warranty on Must-Solar product.

 Q5: How to solve the technical problem?

A5: 24 hours after-service consultancy just for you and to make your problem to solve easily.
