Quick Details

  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: OEM,ODM
  • Model Number: PV3000
  • Output Power: 1 - 200KW
  • Output Type: Single
  • Size: 260x460x185mm
  • Weight: 30kg
  • Input Voltage: 110vac/230vac
  • Output Voltage: 230vac
  • Type: DC/AC Inverters
  • Output Frequency: 50 60hz
  • Output Current: 30A-75A
  • Status display: LCD
  • Photovoltaic(PV) modules: YES
  • Inverter type: Off grid inverter
  • Color: Black or White
  • Frequency: Low frequency
  • DC voltage: 12v/24v
  • Terminal size: #8 AWG
  • MPPT inbuilt: YES
  • Certification: CE/ISO9001
  • Name: Solar Power 3KW inverter for air conditioner

Packaging & Delivery

Packaging Details Cartons or wooden box, Or according to customer's need.
Packing siez: 570*355*300mm(1-3KW), 1pcs/carton, loaded in container: 370pcs/20'ft
MUST POWER LIMITED
David Zhang
+86 13927460042
Skype:mustupsh
Delivery Time Shipped in 15 days after payment

Must Solar Power 3KW inverter for air conditioner

Product Description

What is Solar System ?



Solar pv inverters is an electronic system that operates the photovoltaic(PV) modules in a manner that allows the modules to produce all the power they are capable of. The solar mate charge controller is a microprocessor-based system designed to implement the MPPT. It can increase charge current up to 30% or more compared to traditional charge controllers.



Features of Solar Inverter PV3000:

  • Pure sine wave output
  • Powerful charge rate up to 70Amp
  • Built-in MPPT solar charge controller 40A/60A
  • MPPT efficiency max 98%
  • Built-in pure copper UI transformer
  • DIP Switch offer customized performance
  • High Efficiency Design & “Power Saving Mode” to Conserve Energy
  • Supporting RS232 communication, AGS, BTS port
  • Remote control panel (optional)
  • Compatible to generator

Design of the solar inverter PV3000





Specifications

What is the Technical Specifications of power inverter 1-5KW ?

MODELPV30-1KW MPKPV30-1.5KW MPKPV30-2KW MPKPV30-3KW MPKPV30-4KW MPKPV30-5KW MPKPV30-6KW MPK
Default Battery System Voltage12VDC24VDC12VDC24VDC12VDC24VDC12VDC24VDC24VDC/48VDC24VDC/48VDC24VDC/48VDC
INVERTER OUTPUT
Rated Power1KW1.5KW2KW3KW4KW5KW6KW
Surge Rating (20ms)3KW4.5KW6KW9KW12KW15KW18KW
Capable Of Starting Electric Motor1HP1HP1HP2HP2HP3HP3HP
WaveformPure sine wave/ same as input (bypass mode)Pure sine wave/ same as input (bypass mode)
Nominal Output Voltage RMS100V/110V/120VAC 220V/230V/240VAC(+/-10% RMS)100V/110V/120VAC 220V/230V/240VAC220V/230V/240VAC
Output Frequency50Hz/60Hz +/-0.3 Hz50Hz/60Hz +/-0.3 Hz
Inverter Efficiency(Peak)>88%>88%
Line Mode Efficiency>95%>95%
Power Factor0.81.0
Typical Transfer Time10ms(max)10ms(max)
AC INPUT
Voltage120VAC/230VAC230VAC
Selectable Voltage Range96~132VAC 155~280VAC(For Personal Computers)96~132VAC/155~280VAC(For Personal Computers)
Frequency Range50Hz/60Hz (Auto sensing) 40-80Hz50HZ/60HZ (Auto sensing) 40-80Hz
BATTERY
Minimum Start Voltage10.0VDC /10.5VDC for12VDC mode (*2 for 24VDC, )20.0VDC~21.0VDC /40.0VDC~42.0VDC
Low Battery Alarm10.5VDC +/-0.3V for12VDC mode (*2 for 24VDC, )21.0VDC+/-0.6V /42.0VDC+/-1.2V
Low Battery Cutoff10.0VDC +/-0.3V for12VDC mode (*2 for 24VDC, )20.0VDC+/-0.6V /40.0VDC+/-1.2V
High Voltage Alarm16.0VDC +/-0.3V for12VDC mode (*2 for 24VDC, )32.0VDC+/-0.6V /64.0VDC+/-1.2V
High Battery Voltage Recover15.5VDC +/-0.3V for12VDC mode (*2 for 24VDC, )31.0VDC+/-0.6V / 62.0VDC+/-1.2V
Idle Consumption-Search Mode<25W when power saver on<50W when power saver on
AC CHARGER
Output VoltageDepends on battery typeDepends on battery type
Charger AC Input Breaker Rating10A30A30A30A40A
Overcharge Protection S.D.15.7VDC for 12VDC mode (*2 for 24VDC, )31.4VDC/62.8VDC
Maximum Charge Current35A20A45A25A65A35A75A45A65A35A70A40A75A50A
BYPASS & PROTECTION
Input Voltage WaveformSine wave (grid or generator)Sine wave (grid or generator)
Nominal Input Frequency50Hz or 60Hz50Hz or 60Hz
Overload Protection (SMPS Load)Circuit breakerCircuit breaker
Output Short Circuit ProtectionCircuit breakerCircuit breaker
Bypass Breaker Rating10A15A30A30A40A
Max Bypass Current30Amp40Amp
SOLAR CHARGER
Maximum PV Array Power600W1200W600W1200W600W1200W600W1200W1600W3200W1600W3200W1600W3200W
Maximum PV Charge Current40A60A
DC Voltage12V/24V atuo work24V/48V atuo work
MPPT Range @ Operating Voltage16~100VDC32~145VDC @ 24V / 64~145VDC @ 48V
Maximum PV Array Open Circuit Voltage100VDC145VDC
Maximum Efficiency>90%>98%
Standby Power Consumption<2W<2W

Packaging

Power Inverter Package: Client's OEM Package Welcomed

Power Inverter Shipping



Our Services

Payment & Shipping & Sample

1. Payment: T/T (Telegraphic transfer), and Western Union

2. Shipping: DHL, FEDEX, UPS, EMS, Airway and By Sea

Samples are Available for Testing and Market Test. OEM is welcomed for us.



Guides and After-service Consultancy

  A. Need a Accessory

  B. Products Repair

  C. Power Problems to Solve

  D. Power Protection Solutions, etc.

24 Hours After-service consultancy just for you and to make your problems to solve easily.


Must Power Certificates




Company Information
                                                MUST Power Revenue Growth Increases Every Year
  Must Power Limited Factory Tour
  MUST POWER TOP SALES TEAMS
MUST POWER 2017 Solar Exhibition




FAQ

Q1: How to choose a right inverter?

A1:Tell us your demand, then our sales will recommend a suitable inverter to you.

Q2: What's the different between inverter and solar inverter?

A2:  Inverter is only accept AC input, but solar inverter not only accept AC input but also can connect with solar panel to accept PV input, it more save power.

Q3: How about the delivery time?

A3:  7 days for sample; 25 days for bulk order.

Q4: What is the warranty of inverter?

A4: One year warranty on Must-Solar product.

Q5: How to solve the technical problem?

A5: 24 hours after-service consultancy just for you and to make your problem to solve easily.
