Quick Details
- Place of Origin: Guangdong, China (Mainland)
- Brand Name: MUST,OEM,ODM
- Model Number: EP3000 Pro
- Output Power: 1 - 50W
- Output Type: Single
- Size: 580*365*310mm
- Weight: 19.3-49.3KGS
- Input Voltage: 220V/230V/240V
- Output Voltage: 110V/220V/230V/240V
- Type: Off grid inverter
- Output Frequency: 50/ 60hz
- Output Current: 30-70A
- waveform: Pure Sine Wave
- Frequency: Low frequency
- Inverter type: Off grid inverter
- DC voltage: 12v/24v/48V
- Color: Red or Silver Iron case
- Display: LCD Display
- Protection: Overload&short circuit protection
- Application: Solar System
- Name: DC to AC 3000W Power inverter air conditioner
- Warranty: 12 Months
Packaging & Delivery
| Packaging Details: | Cartons or wooden box, Or according to customer's need.
580*365*310mm MUST POWER LIMITED |
|---|---|
| Delivery Detail: | Shipped in 15 days after payment |
EP3000pro DC to AC 1-3KW Power inverter with Pure Copper transformer inversor
1.What is the Features of Power Inverter EP3000 pro series?
1. 1kw/1.5kw/2kw/2.5kw/3kw/3.5kw/4kw/5kw/6kw
2. Max. charge current 75A.
3.Pure sine wave.
4. Inbuilt pure copper transformer
5. Support inductive load
6. Automatic three-stage batteryCharger (bulk, absorption, float)
7. Support generator
8. Support solar system (need to connect a extra solar controller)
9. RS232 function
10. CE/ SONCAP certificate
11. Support motor 1HP/2HP/3HP
2.What is the LCD Display information of Power Inverter EP3000 pro series?
3.What is the design of Power Inverter EP3000 pro series?
What is the Technical Specifications of Power Inverter EP3000 pro ?
| MODEL | EP30-1KW PRO | EP30-1.5KW PRO | EP30-2KW PRO | EP30-3KW PRO | EP30-4KW PRO | EP30-5KW PRO | EP30-6KW PRO | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Default Battery System Voltage | 12VDC | 24VDC | 12VDC | 24VDC | 12VDC | 24VDC | 12VDC | 24VDC | 48VDC | 24VDC | 48VDC | 24VDC | 48VDC | 24VDC | 48VDC | |
| INVERTER OUTPUT | Reted Power | 1.0KW | 1.5KW | 2KW | 3KW | 4KW | 5KW | 6KW | ||||||||
| Surge Rating (20ms) | 3.0KVA | 4.5KVA | 6.0KVA | 9.0KVA | 12KVA | 15KVA | 18KVA | |||||||||
| Capable Of Starting Electric Motor | 1HP | 1HP | 1HP | 2HP | 3HP | |||||||||||
| Waveform | Pure sine wave/ same as input (bypass mode) | |||||||||||||||
| Nominal Output Voltage RMS | 100V/110V/120VAC 220V/230V/240VAC(±10% RMS) | 220V/230V/240VAC(±10% RMS) | ||||||||||||||
| Output Frequency | 5OHz/60Hz±0.3 Hz | |||||||||||||||
| Inverter Efficiency(Peak) | >88% | |||||||||||||||
| Line Mode Efficiency | >95% | |||||||||||||||
| Power Factor | 1.0 | |||||||||||||||
| Typical Transfer Time | 10ms(max) 10ms(max) | |||||||||||||||
| AC INPUT | Voltage | 230VAC | ||||||||||||||
| Selectable Voltage Range | 96~132VAC 155~280VAC(For Personal Computers) | |||||||||||||||
| Frequency Range | 50Hz/60Hz (Auto sensing) 40~80Hz | |||||||||||||||
| BATTERY | Minimum Start Voltage | 10.0VDC /10.5VDC for12VDC mode (*2 for 24VDC, ) | ||||||||||||||
| Low Battery Alarm | 10.5VDC±0.3V for12VDC mode (*2 for 24VDC, ) | |||||||||||||||
| Low Battery Cutoff | 10.0VDC±0.3V for12VDC mode (*2 for 24VDC, ) | |||||||||||||||
| High Voltage Alarm | 16.0VDC±0.3V for12VDC mode (*2 for 24VDC, ) | |||||||||||||||
| High Battery Voltage Recover | 15.5VDC±0.3V for12VDC mode (*2 for 24VDC, ) | |||||||||||||||
| Idle Consumption-Search Mode | <25W when power saver on | |||||||||||||||
| CHARGER | Output Voltage | Depends on battery tvpe | ||||||||||||||
| Charger AC Input Breaker Rrating | 10A | 30A | 30A | 30A | 40A | |||||||||||
| Overcharge Protection S.D. | 15.7VDC for 12VDC mode (*2 for 24VDC mode) | |||||||||||||||
| Maximum Charge Current | 35A | 20A | 45A | 25A | 65A | 35A | 75A | 45A | 30A | 65A | 35A | 70A | 40A | 75A | 50A | |
| BYPASS & PROTECTION | Input Voltage Waveform | Sine wave (grid or generator) | ||||||||||||||
| Nominal Input Frequency | 50Hz or 60Hz | |||||||||||||||
| Overload Protection (SMPS Load) | Circuit breaker | |||||||||||||||
| Output Short Circuit Protection | Circuit breaker | |||||||||||||||
| Bypass Breaker Rating | 10A | 30A | 30A | 30A | 40A | |||||||||||
| Max Bypass Current | 30Amp | |||||||||||||||
| SOLAR CHARGER | Maximum PV Charge Current | 50A | ||||||||||||||
| DC Voltage | 12V/24V/48 | |||||||||||||||
| PWM Range @ Operating Voltage | 15~80VDC | |||||||||||||||
| Maximum PV Array Open Circuit Voltage | 90VDC | |||||||||||||||
| Maximum Efficiency | >97% | |||||||||||||||
| Standby Power Consumption | <2W | |||||||||||||||
| MECHANICAL SPECIFICATIONS | Mounting | Wall mount | ||||||||||||||
| Dimensions (W*H*D) | 426*206*178 mm | 601*206*178 | ||||||||||||||
| Net Weight (Solar CHG) kg | 16.5 | 17 | 21.1 | 20 | 26 | 24.5 | 24.8 | 38.2 | 35.8 | 45.2 | 45 | 45.2 | 45 | |||
| Shipping Dimensions(W*H*D) | 570*335*300mm | 750*335*300mm | ||||||||||||||
| Shipping Weight (Solar CHG) kg | 19.3 | 20 | 24.1 | 22.8 | 29.1 | 27.5 | 27.5 | 42.3 | 40 | 49.5 | 49.3 | 49.5 | 49.3 | |||
| OTHER | Operation Temperature Range | 0°C to 40°C | ||||||||||||||
| Storage Temperature | -15°C to 60°C | |||||||||||||||
| Audible Noise | 60dB MAX | |||||||||||||||
| Display | LED+LCD | |||||||||||||||
| Standard Warranty | 1 year | |||||||||||||||
Power Inverter Package: Client's OEM Package Welcomed
Power Inverter Shipping
Payment & Shipping & Sample
1. Payment: T/T (Telegraphic transfer), and Western Union, and also could accept Trade Assurance.
2. Shipping: DHL, FEDEX, UPS, EMS, Airway and By Sea
Samples are Available for Testing and Market Test. OEM is welcomed for us.
One Year Warranty on MUST POWER Products
Guides and After-service Consultancy
A. Need a Accessory
B. Products Repair
C. Power Problems to Solve
D. Power Protection Solutions, etc.
Must Power Limited
| Headquarter & Factory Location | In HongKong & Shenzhen,Guangdong China Mainland |
| Industry Experience | 6-Year Manufacturer, 12-Year Trading, 6-Year Alibaba Gloden Supplier |
| Product Range | Inverter,Solar Inverter, Off-grid Inverter Grid-tie Solar Inverter, MPPT Solar Charge Controller, Solar Panel, Solar Battery, Solar System |
| Main Market | Africa, Middle East & Asia ( Ukraine, Russia, Vietnam, Pakistan, Nigeria, Kenya, South Africa, Ghana,etc.) |
| Factory | 8000 Square Meters, 200 workers |
| Department | 7-team Marketing Dept, 2-team R&D, 1 Manufacturing Center, QA Office, After-sale Service Dept. |
| Certificate | ISO9001:2008, CE, IEC,SAA, SGS, Soncap,etc |
| Patent | Software Patent, Design Patent, Project Patent |
Q1: How to choose a right inverter?
A1:Tell us your demand, then our sales will recommend a suitable inverter to you.
Q2: What's the different between inverter and solar inverter?
A2: Inverter is only accept AC input, but solar inverter not only accept AC input but also can connect with solar panel to accept PV input, it more save power.
Q3: How about the delivery time?
A3: 7 days for sample; 25 days for bulk order.
Q4: What is the warranty of inverter?
A4: One year warranty on Must-Solar product.
Q5: How to solve the technical problem?
A5: 24 hours after-service consultancy just for you and to make your problem to solve easily.
