Quick Details

  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: OEM
  • Model Number: EP3000 Pro
  • Output Power: 1 - 200KW
  • Output Type: Single
  • Size: 423*224*180mm
  • Weight: 18-48kg
  • Input Voltage: 12V/24V/48V
  • Output Voltage: 110V/220V/230V/240V
  • Type: DC/AC Inverters
  • Output Frequency: 50Hz/60Hz
  • Output Current: 20A-75A
  • Output waveform: pure sine wave output
  • Rated power: 1000W-12000W
  • Surge power: 3*rated Start Power
  • Frequency: 50Hz/60HZ
  • Phase: single phase
  • Protection: overload, short circuit protection
  • Display: LED+LCD Display
  • Warranty: 12 Months
  • Battery priority: yes
  • Inverter type: Off-grid Inverter

Packaging & Delivery

Packaging Details: Cartons or wooden box, or according to customer's need.
Packing size: 755*319*288mm (4kw-6kw)
570*315*300mm (1kw-3kw)
1pc/carton
Delivery Detail: Shipped in 25 days after payment

pure sine wave 10KW UPS low frequency power convertor 10000w power inverter

Model: EP3000 Pro  1KW-12KW

Welcome to contact Angel: Whatsapp/ Mob: +86 13823339627   Skype:mustupsl



Product Description

 Part One: Features of the Low Frequency Inverter EP3000 Pro

1. low frequency pure sine wave

2. Adopting “UI type” transforme

3. Charge current is adjustable-25%, 50%, 75%, 100%

4. Inbuilt pure copper transformer

5. Low battery, overload, and high battery, over temperature protection

6. Battery or AC priority

7. RS232/ Remote switch controller

8. Generator compatible

9. AC charging current: 35A to 70A

10. rated power 1kw-12kw





Part Two: Advantages of the new model EP3000 Pro Inverter



1) New design of the back panel: there is RS232, AGS, BTS ports, and DIP switch





2) For the transformer:

* Adopting “UI type” transformer for the 4-6KW;

* enchancing DC to AC efficiency to 88% peak;

* and ultra low idle consumption 90W





3) with AGS:

Auto Generator Start for back up electrical generators in renewable system.
This terminal can also be connected to external alarm devices
to give alarm when battery voltage goes low.



4) BTS terminal:

Battery temperature sensor: regulating charging voltage ,based on different temperature .It is very IMPORTANT in hot country .When too high temperature,it can reduce charging voltage, to protecting battery from swelling



5) DIP Switch: Offer customized performance

(SW1) : Control low battery trip voltage

(SW2): Input AC voltage selector(145-272V or 184V-272Vac)

(SW3): Power save mode detecting time (5 secs or 30 secs)

(SW4): Output frequency selector (50Hz or 60Hz)

(SW5): Solar/ AC priority selector



MUST Production Process





Part Three: Full specification of the Low frequency Inverter



MODELEP30-4KWEP30-5KWEP30-6KW
Default Battery System Voltage24V48V24V48V24V48V
INVERTER OUTPUTReted Power4000W5000W6000W
Surge Rating (20ms)12000VA15000VA18000VA
Capable Of Starting Electric Motor2HP3HP
WaveformPure sine wave/ same as input (bypass mode)
Nominal Output Voltage RMS100V/110V/120VAC  220V/230V/240VAC 220V/230V/240VAC
Output Voltage Regulation±10% RMS
Output Frequency5OHz/60Hz±0.3 Hz
Inverter Efficiency(Peak)>88%
Line Mode Efficiency>95%
Power Factor1.0
Typical Transfer Time10ms(max)
AC INPUTVoltage120VAC/230VAC
Selectable Voltage Range96~132VAC 155~280VAC(For Personal Computers) 155~280VAC(For Computers)
Frequency Range50Hz/60Hz (Auto sensing)  40~80Hz
BATTERYMinimum Start Voltage10.OVDC/10.5VDC for12VDC mode (*2 for 24VDC, *4 for 48VDC)
Low Battery Alarm10.5VDC±0.3V for12VDC mode (*2 for 24VDC, *4 for 48VDC)
Low Battery Cutoff10.0VDC±0.3V for12VDC mode (*2 for 24VDC, *4 for 48VDC)
High Voltage Alarm16.0VDC±0.3V for12VDC mode (*2 for 24VDC, *4 for 48VDC)
High Battery Voltage Recover15.5VDC±0.3V for12VDC mode (*2 for 24VDC, *4 for 48VDC)
Idle Consumption-Search Mode<25W when power saver on
CHARGEROutput VoltageDepends on battery type
Charger AC Input Breaker Rrating40A
Overcharge Protection S.D.15.7VDC for 12VDC mode (*2 for 24VDC, *4 for 48VDC)
Maximum Charge Current65A35A70A40A75A50A
BTSContinuous Output PowerYes Variances in charging voltage & S.D. voltage base on the battery temperature
BYPASS & PROTECTIONInput Voltage WaveformSine wave (grid or generator)
Nominal Input Frequency50Hz or 60Hz
Overload Protection (SMPS Load)Circuit breaker
Output Short Circuit ProtectionCircuit breaker
Bypass Breaker Rating40A
Max Bypass Current40Amp
MECHANICAL SPECIFICATIONSMountingWall mount
Dimensions (W*H*D)185*160*600
Net Weight (kg)37.234.844.24444.244
Shipping Dimensions(W*H*D)319*288*755
Shipping Weight (kg)40.838.44847.84847.8
OTHEROperation   Temperature  Range0°C to 40°C
Storage   Temperature-15°C to 60°C
Audible   Noise60dB MAX
DisplayLED+LCD
Standard Warranty1 year



the related products with inside MPPT charge controller:

https://www.alibaba.com/product-detail/off-grid-pure-sine-wave-inverter_60601997056.html?spm=a2747.manage.list.49.9J5Gd4



 MUST Service:



MUST will have an office in Pakistan for After-sales service, then all over the world



Trade Assurance----You will get refund up to 100% Trade Assurance Order amount if the goods is not shipped on time or does not meet the quality requirements



24 hours Online----You will get my quotation and response within 24hours



12 months warranty----You will get the spare parts and maintaince guides if any break dowm



Available spare parts----You will get the spare parts for after-sale service



After-sale service----You will be servised by the professional after-sale service center if any problems



To be regular clients or Agents of MUST----You will get the beautiful gifts and many Preferencial Policy



24 Hours After-service consultancy just for you and to make your problems to solve easily.
(Angel Lee  Skype:mustupsl    Whatsapp:+86 13823339627)


Company Information



 MUST Power Ltd Mile-Stone





Testing Machine&Aging room



Aging Room: every procuct will be placed in the againg room to test at least 4hours, and the engineers and employees of MUST will change the working mode during this time.



MUST Power Ltd. world tour exihibition in 2017



 MUST Professional International Sales Team
Packaging & Shipping



Cartons or wooden box, or according to customer's need.
Packing size:

755*319*288mm (4kw-6kw)
570*315*300mm (1kw-3kw)
1pc/carton

 Shipping:

For samples, like 1-3pcs, you'd better choose by air or by express; for bulk order, all is upon your choice



Our Services

 Good News:



Place order via Trade Assurance

You will get:

1) 100% money refund for quality problems or late shipment

2) You will get refund up to 100% trade assurance amount if the goods is not shipped online

3) You can pay by your credit card.

Samples are Available for Testing and Market Test. OEM is welcomed for us.

1-Year Warranty on MUST POWER Products

Guides and After-sell service Consultancy

Must Power Team will offer these guides below.

  A. Need a Accessory

  B. Products Repair

  C. Power Problems to Solve

  D. Power Protection Solutions, etc.

24 Hours After-service consultancy just for you and to make your problems to solve easily.
(Angel Lee  Skype:mustupsl    Whatsapp:+86 13823339627)





FAQ



1. Q: Can I have sample before formal order?

     A: Sure, it will be warm welcomed.



2. Q: What's the warranty:

    A: 12 months.



3. Q: What's the payment methods?

    A: Usually we accept T/T  (Telegraphic Transfer), and Western Union.



4. Q: OEM is available?

    A: Yes, OEM is welcomed.



Why not give both of us a chance to know each other and share the world together? Just move you fingers and click "SEND" button below, and lets talk!!
