Quick Details

  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: OEM or MUST
  • Model Number: PV3000 PK
  • Output Power: 1 - 200KW
  • Output Type: Single
  • Size: 460*277*192mm~597*277*198mm
  • Weight: 18.3KG~48.6KG
  • Input Voltage: 12V/24V/48V
  • Output Voltage: 100V/110V/120V/220V/230V/240V
  • Type: DC/AC Inverters
  • Output Frequency: 50Hz/60Hz
  • Output Current: 50A
  • Output waveform: pure sine wave
  • AC voltage: 110V / 220V
  • Surge power: 3 Times
  • Battery Voltage: 12V/ 24V/48V DC
  • Max PV charge current: 50A
  • Frequency: 50Hz/60HZ Auto sensing
  • Display: LED+LCD
  • Warranty: 12 Months
  • RS232: Yes
  • Battery priority: Yes

Packaging & Delivery

Packaging Details 1pc/caron
1kw-3kw:
Size: 580x365x310mm
weight: 31kg
4kw-6kw:
Size: 753x382x322mm
weight: 54kg
Delivery Time Shipped in 25 days after payment

South America 1000W to 6000W 110V converter solar inverter with PWM controller



Model: PV3000 PK 1KW-6KW 12V/ 24V/ 48V

Welocme to contact with Angel: +86 13823339627  Skype:mustupsl





Main features:

* low frequency pure sine wave

* function switch (SW1~SW5)

* AGS (auto generator start)

* BTS (battery temperature sensor)

* inbuilt PWM solar charge controller 50A

* battery priority function

* 12V/ 24V/ 48V input optional

* Max AC charge current 70A

* inbuilt pure copper transformer

* 50Hz/60Hz sense automatically

* RS232 communication







Product Description

1) new function of the solar inverter PV3000 PK model:



- AGS: auto generator start



- DIP switch function (SW1~SW5)



- BTS: battery temperature sensor





2) Details about the terminals: PV input, AC in/output, battery connection, fan cooling, DIP switch, BTS, AGS





3) LED+LCD display for easy setting and operation: setting operation mode via LCD, such as PV priority mode, AC priority mode, frequency 50Hz or 60Hz setting.



4) Connection& Diagram: hybrid one for connecting both PV and AC



 Full Specification of Solar Power Inverter PV3000 PK



MODELPV30-1KWPV30-1.5KWPV30-2KWPV30-3KWPV30-4KWPV30-5KWPV30-6KW
Default Battery System Voltage (DC)12V24V12V24V12V24V12V24V48V24/48V24/48V24/48V
INVERTER OUTPUTRated Power1KW1.5KW2KW3KW4KW5KW6KW
Surge Rating (20ms)3KW4.5KW6KW9KW12KW15KW18KW
Capable Of Starting Electric Motor1HP1HP1HP2HP2HP3HP3HP
WaveformPure sine wave/ same as input (bypass mode)
Nominal Output Voltage RMS100V/110V/120VAC  220V/230V/240VAC(+/-10% RMS)220V/230V/240VAC(+/-10% RMS)
Output Frequency50Hz/60Hz +/-0.3 Hz
Inverter Efficiency(Peak)>88%
Line Mode Efficiency>95%
Power Factor0.8
Typical Transfer Time10ms(max)
AC INPUTVoltage120VAC/230VAC230VAC
Selectable Voltage Range96~132VAC  155~280VAC(For Personal Computers)
Frequency Range50Hz/60Hz (Auto sensing) 40-80Hz
BATTERYMinimum Start Voltage10.0VDC /10.5VDC for12VDC mode (*2 for 24VDC, *4 for 48VDC )
Low Battery Alarm10.5VDC +/-0.3V for12VDC mode (*2 for 24VDC, *4 for 48VDC )
Low Battery Cutoff10.0VDC +/-0.3V for12VDC mode (*2 for 24VDC, *4 for 48VDC )
High Voltage Alarm16.0VDC +/-0.3V for12VDC mode (*2 for 24VDC, *4 for 48VDC )
High Battery Voltage Recover15.5VDC +/-0.3V for12VDC mode (*2 for 24VDC, *4 for 48VDC )
Idle Consumption-Search Mode<25W when power saver on
AC CHARGEROutput VoltageDepends on battery type
Charger AC Input Breaker Rating10A30A30A30A40A
Overcharge Protection S.D.15.7VDC for 12VDC mode (*2 for 24VDC, *4 for 48VDC )
Maximum Charge Current35A20A45A25A65A35A75A45A30A65A35A70A40A75A50A
BYPASS
& PROTECTION
Input Voltage WaveformSine wave (grid or generator)
Nominal Input Frequency50Hz or 60Hz
Overload Protection (SMPS Load)Circuit breaker
Output Short Circuit ProtectionCircuit breaker
Bypass Breaker Rating10A30A30A30A40A
Max Bypass Current30Amp
SOLAR CHARGERMaximum PV Charge Current50A
DC Voltage12V/24V/48V
MPPT Range @ Operating Voltage15~80VDC
Maximum PV Array Open Circuit Voltage90VDC
Maximum Efficiency>97%
Standby Power Consumption<2W
MECHANICAL
SPECIFICATIONS
MountingWall mount
Dimensions (W*H*D)426*206*178 mm601*206*178mm
Net Weight (Solar CHG) kg16.51721.1202624.524.838.235.845.24545.245
Shipping Dimensions(W*H*D)570*335*300mm750*335*300mm
Shipping Weight (Solar CHG) kg19.32024.122.829.127.527.542.34049.549.349.549.3
OTHEROperation Temperature Range0°C to 40°C
Storage Temperature-15°C to 60°C
Audible Noise60dB MAX
DisplayLED+LCD



Related product without inside MPPT solar charge controller is EP3000 Pro:

https://www.alibaba.com/product-detail/110v-120v-220v-230v-240v-ac_60625532841.html?spm=a2747.manage.list.82.lDFaYc



 MUST production process:

 MUST Service:



MUST has an office in Pakistan, and the office will be in all over the world to offer service



Trade Assurance----You will get refund up to 100% Trade Assurance Order amount if the goods is not shipped on time or does not meet the quality requirements



24 hours Online----You will get my quotation and response within 24hours



12 months warranty----You will get the spare parts and maintaince guides if any break dowm



Available spare parts----You will get the spare parts for after-sale service



After-sale service----You will be servised by the professional after-sale service center if any problems



To be regular clients or Agents of MUST----You will get the beautiful gifts and many Preferencial Policy



24 Hours After-service consultancy just for you and to make your problems to solve easily.
(Angel Lee  Skype:mustupsl    Whatsapp:+86 13823339627)



Company Information

MUST Power Limited Brief introduction





MUST Full CE Approval& Golden Supplier of Alibaba



MUST Testing Machine&Aging room& Production line

All together there is 8 production lines, and there is quality testing amchine at the end of each line so that we could control the quality very well.



Aging Room: every procuct will be placed in the againg room to test at least 4hours, and the engineers and employees of MUST will change the working mode during this time.





MUST Power exhibition in 2016





Packaging & Shipping

 Packing for PV3000 PK:

1pcs/carton

Cartons or wooden box, or according to customer's need.



1kw-3kw:
Size: 580x365x310mm
weight: 31kg



4kw-6kw:
Size: 753x382x322mm
weight: 54kg





Shipping for PV3000 PK:

For samples, like 1-3pcs, you'd better choose by air or by express; for bulk order, all is upon your choice

Our Services



Good News:



Place order via Trade Assurance

You will get:

1) 100% money refund for quality problems or late shipment

2) You will get refund up to 100% trade assurance amount if the goods is not shipped online

3) You can pay by your credit card.

Samples are Available for Testing and Market Test. OEM is welcomed for us.

1-Year Warranty on MUST POWER Products

Guides and After-sell service Consultancy

Must Power Team will offer these guides below.

  A. Need a Accessory

  B. Products Repair

  C. Power Problems to Solve

  D. Power Protection Solutions, etc.

24 Hours After-service consultancy just for you and to make your problems to solve easily.
(Angel Lee  Skype:mustupsl    Whatsapp:+86 13823339627)

 MUST Professional International Sales Team
FAQ



1. Q: Can I have sample before formal order?

     A: Sure, it will be warm welcomed.



2. Q: What's the warranty:

    A: 12 months.



3. Q: What's the payment methods?

    A: Usually we accept T/T  (Telegraphic Transfer), and Western Union.



4. Q: OEM is available?

    A: Yes, OEM is welcomed.
