Quick Details

  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: OEM ODM
  • Model Number: PC1600A
  • Application: Charger Controller
  • Rated Voltage: 12V/24V/36V/48V
  • Maximum Current: 60A
  • Charge mode: Maximum Power Point Tracking
  • Type: MPPT charge controller
  • System voltage: 12V/24V/48V Auto
  • Rated Current: 45A/60A
  • MPPT efficiency: >99%
  • Display: LCD
  • Loads: air condition, DC light, computer
  • Color: red, silver, green
  • Warranty: 12 Months
  • Certification: CE/RoHS/IEC

Packaging & Delivery

Packaging Details: 1pc/carton
packing size: 462*295*220mm
shipping weight: 8kg
net weight: 6.8kg
Delivery Detail: Shipped in 25 days after payment

CE certificated 12V 24V 48V auto sensing 45A 60A MPPT solar charge controller



Model No: PC1600A  capacity: 45A~60A MPPT



welcome to contact Angel: Mob/ whatsapp: +86 13823339627   Skype: mustupsl



Product Description



Brief Introduction of main features for the Power Inverter



Details of Air Cooling 45A MPPT Solar Charge Controller:









Back terminals:





Connection in Solar systems:

Full Specification of the Solar Charge Controller



ModelPC16-4515APC16-6015A
Default Battery System Voltage12V/24V/36V/48VDC (adjustable)
CONTROLLER
INPUT
PV Open Circuit Voltage Range145VDC
Max PV Input Power(12V)600W800W
Max PV Input Power(24V)1200W1600W
Max PV Input Power(36V)1800W2400W
Max PV Input Power(48V)2400W3200W
BATTERYPeak Conversion effciency98%(MPPT Efficiency 99%)
Max Charging Current45amps continuous60 amps continuous
Absorption Voltage13.5VDC/27.0VDC/40.5VDC/54VDC
Refloat Voltage13.7VDC/27.4VDC/41.4VDC/54.8VDC
Float Voltage14.3VDC/28.6VDC/42.9VDC/57.4VDC
Low Voltage Protection Point10.5VDC/21.0VDC/31.5VDC/42VDC
DC
OUTPUT
Output Voltage11.0-14.3VDC/22-28.6VDC/33-42.9VDC/44-57.4VDC
Max Load Current45amps continuous60 amps continuous
Warning for low voltage11.5VDC/23.0VDC/34.5VDC/46VDC
Cutoff for low voltage10.5VDC/21.0VDC/31.5VDC/42VDC
Low voltage recovery11.5VDC/23.0VDC/34.5VDC/46VDC
GENERAL SPECIFICATIONCharge modeMPPT, PWM, constant current-constant voltage, function of automatic protection for storage battery
Radiating modeAutomatic cooling
Working modeFour stage: Absorption CC, Absorption CV, Float CC, Float CV
DISPLAY & PROTECTIONLED indicationSystematic operation, LV indication, LV protection, over charge protection, loads protection, short circuit protection
LCD displayCharge voltage, charge current, voltage of storage battery, capacity of storage battery, output current
Alarm ProtectionsPV array short circuit, PV reverser polarity
Battery reverse polarity, Over charging protection
Output short circuit protection
Low voltage protection for storage battery
MECHANICAL
SPECIFICATIONS
MountingWall mount
W*H* D(mm)/G.W(kg)205*372*123mm/6kg
OTHEREnvironmental RatingIndoor
Operation Temperature Range-25~55°C
Ambient humidity0~90% relative humidity(non-condensing)
Altitude≤3000m
Loading(20GP/40GP/40HQ)5500pcs/11000pcs/13000pcs



MUST production process:







MUST 2017 exhibition news:

Company Information

 Brief Introduction of MUST Power Ltd



MUST factory show





Aging Room: every procuct will be placed in the againg room to test at least 4hours, and the engineers and employees of MUST will change the working mode during this time to control the quality.



Packaging & Shipping

 Packing:



1pc/carton
packing size: 462*295*220mm
shipping weight: 8kg
net weight: 6.8kg



Shipping:

For samples, like 1-3pcs, you'd better choose by air or by express; for bulk order, all is upon your choice



Our Services



MUST will have an office in Pakistan, and then the office will be all over the world



Trade Assurance----You will get refund up to 100% Trade Assurance Order amount if the goods is not shipped on time or does not meet the quality requirements



24 hours Online----You will get my quotation and response within 24hours



12 months warranty----You will get the spare parts and maintaince guides if any break dowm



Available spare parts----You will get the spare parts for after-sale service



After-sale service----You will be servised by the professional after-sale service center if any problems



To be regular clients or Agents of MUST----You will get the beautiful gifts and many Preferencial Policy





24 Hours After-service consultancy just for you and to make your problems to solve easily.
(Angel Lee  Skype:mustupsl    Whatsapp:+86 13823339627)


Good News:



Place order via Trade Assurance

You will get:

1) 100% money refund for quality problems or late shipment

2) You will get refund up to 100% trade assurance amount if the goods is not shipped online

3) You can pay by your credit card.



Samples are Available for Testing and Market Test. OEM is welcomed for us.

1-Year Warranty on MUST POWER Products

Guides and After-sell service Consultancy

Must Power Team will offer these guides below.

  A. Need a Accessory

  B. Products Repair

  C. Power Problems to Solve

  D. Power Protection Solutions, etc.

24 Hours After-service consultancy just for you and to make your problems to solve easily.
(Angel Lee  Skype:mustupsl    Whatsapp:+86 13823339627)

 MUST Professional International Sales Team

FAQ



1. Q: Can I have sample before formal order?

     A: Sure, it will be warm welcomed.



2. Q: What's the warranty:

    A: 12 months.



3. Q: What's the payment methods?

    A: Usually we accept T/T  (Telegraphic Transfer), and Western Union.



4. Q: OEM is available?

    A: Yes, OEM is welcomed.





 Just move your finger and click the "SEND" below to send inquiry, we will start discussion and share the world markets together. Angel is here waiting for your inquiry.
